Output

Max Configurable Power (Watts)

550 Watts / 1.1kVA

Output Frequency (sync to mains)

50/60 Hz +/- 1 Hz Sync to mains, 50/60 Hz +/- 1 Hz Unsynchronised

Topology

Line interactive

Waveform type

Stepped approximation to a sinewave

Transfer Time

4 ms typical : 6 ms maximum

Input

Input frequency

50/60 Hz +/- 3 Hz Auto-sensing

Input voltage range for main operations

150 - 280 V

Number of Power Cords

1

Type of Input Protection Required

3-pole circuit breaker

Input Power Factor at Full Load

0.5

Batteries & Runtime

Battery type

Lead-acid battery

Included Battery Modules

1

Typical recharge time

6hour(s)

Replacement Battery

RBC17

Expected Battery Life (years)

2 - 4

Battery Charge Power (Watts)

16 Watts

Communications & Management

Control panel

LED status display with load and battery bar-graphs and on line : on battery : replace battery : and overload indicators

Audible Alarm

Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge Protection and Filtering

Surge energy rating

273Joules

Physical

Maximum Height

215MM, 21.5CM

Maximum Width

130MM, 13.0CM

Maximum Depth

336MM, 33.6CM

Net Weight

9.2KG

Shipping weight

10.6KG

Shipping Height

295MM, 29.5CM

Shipping Width

245MM, 24.5CM

Shipping Depth

440MM, 44.0CM

Color

Black

SCC Codes

10731304315169

Environmental

Operating Temperature

0 - 40 °C

Operating Relative Humidity

0 - 95 %

Operating Elevation

0 - 3048meters

Storage Temperature

-15 - 40 °C

Storage Elevation

0 - 9144meters

Audible noise at 1 meter from surface of unit

45.0dBA
