EXCERIA G2 SSD Product Specifications

Physical

Capacity: 1TB, 2TB

Form Factor: M.2 Type 2280-S2-M

Interface: PCI Express® Base Specification Revision 3.1a (PCIe®)

Flash Memory Type: BiCS FLASH™ TLC

Interface Maximum Speed: 32 GT/s (PCIe® Gen3 x4)

Dimension (Max: LxWxH): 80.15 x 22.15 x 2.23 mm

Interface Command: NVM Express™ Revision 1.3c command set

Weight

1TB: 6.8 g (typ.)

2TB: 7.1 g (typ.)

Performance

Max Sequential Read Speed(1): 2,100 MB/s

Max Sequential Write Speed(1): 1,700 MB/s

Max Random Read Speed(2): 1TB 400,000 IOPS / 2TB 360,000 IOPS

Max Random Write Speed(2): 400,000 IOPS

Endurance: TBW(3)

1TB: 400 TB

2TB: 800 TB

MTTF: 1.5 million hours

Environmental

Operating Temperature: 0 °C (Ta) to 85 °C (Tc)

Storage Temperature: -40 °C to 85 °C

Shock Resistance: 9.806 km/s2 {1,000 G} 0.5 ms half sine wave

Vibration: 196 m/s2 {20 G} Peak, 10~2,000 Hz, (20 min / Axis) x 3 Axis

Supply Voltage: 3.3 V ±5 %

Power Consumption

PS3: 50 mW (typ.)

PS4: 5 mW (typ.)

Power Consumption (Active)

1TB: 3.5 W (typ.)

2TB: 5.3 W (typ.)

Compatibility

PCI Express

Compatible with PCI Express® Base Specification Revision 3.1a and NVM Express™ Revision 1.3c command set

Connector Type

M.2 M key Socket

Target Applications

Client desktops and laptops
