SERIES

Elite Series

SIZE

Mid Tower

MODEL NUMBER

E500-KN5N-S00 (Steel, ODD)

AVAILABLE COLOR(S)

Black

MATERIALS

Steel, Plastic, Tempered Glass

DIMENSIONS (L X W X H)

409 x 204 x 455mm (incl. Protrusions), 402 x 204 x 455mm (excl. Protrusions), 464 x 204 x 455mm (incl Protrusions, ODD), 457 x 204 x 455mm (excl. Protrusions, ODD)

VOLUME (EXLC. PROTRUSIONS)

42.40L (E500-KN5N-S00)

MOTHERBOARD SUPPORT

Mini ITX, Micro ATX, ATX

EXPANSION SLOTS

7

5.25" DRIVE BAYS

1 (E500-KN5N-S00)

2.5" / 3.5" DRIVE BAYS (COMBO)

2

2.5" DRIVE BAYS

5 (E500-KN5N-S00)

I/O PANEL

2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic)

PRE-INSTALLED FANS - REAR

1x 120mm

FAN SUPPORT - TOP

2x 120mm, 2x 140mm

FAN SUPPORT - FRONT

2x 140mm, 3x 120mm (E500-KGNN-S00, E500-KNNN-S00), 2x 120mm (E500-KGNN-S00, E500-KNNN-S00), 3x 120mm (remove ODD bracket) (E500-KGNN-S00, E500-KNNN-S00)

FAN SUPPORT - REAR

1x 120mm

RADIATOR SUPPORT - TOP

120 / 240mm (32mm max motherboard component height)

RADIATOR SUPPORT - FRONT

120mm, 140mm, 240mm, 280mm, 360mm (Remove ODD) (E500-KN5N-S00)

RADIATOR SUPPORT - REAR

120mm

CLEARANCE - CPU COOLER

Steel: 163mm

CLEARANCE - PSU

180mm (E500-KN5N-S00)

CLEARANCE - GFX

400mm (w/o front fans & radiator) (E500-KN5N-S00)

CABLE ROUTING

18.5mm

DUST FILTERS

Front, Top, Bottom

POWER SUPPLY SUPPORT

Bottom mount, ATX

WARRANTY

2 years

Technical Details:
